DC Small Quiet Blower

Introduction

The DC Small Quiet Blower converts electrical energy into mechanical energy. The air inlet and the air outlet are in the vertical wind direction. The air is continuously compressed to create a high volume, and then it can be blown. Such devices are collectively referred to as DC blowers. The product is generally composed of an impeller, casing, current collector, motor, and transmission parts. It can be used for ventilation and air induction of boilers and industrial furnaces, and can also be used for ventilation or dust removal in factories, workshops, warehouses, and other places. While purifying the working environment, it can ensure that mechanical equipment or other industrial products maintain the original quality.

Features

1. The extremely small size of the DC Small Quiet Blower makes it ideal for small household appliances such as induction hobs.

2. The product has extremely low noise during operation, so it will not cause adverse effects on the surrounding environment.

3. The impeller has no friction inside, so the discharged gas does not contain oil, making this product an ideal source of gas for chemical, food, and other industries.

4. The product has a high rotating speed, and the clearance between the rotor and the rotor and between the rotor and machine body is small, so the leakage is small and the volumetric efficiency is high.

5. The rotor, casing, and ring gear have sufficient mechanical strength, so the service life is long.

Details

Product Name: DC Small Quiet Blower

Material: PBT

Working mode: S1

Insulation class: class B

Protection class: IP42

Temperature range: -20~+70℃

Certification: UL/CUL/CE/CCC

Available Features: Tachilable output, autorestart, soft startup, pulse width modulation, control input 0-5V
